LAST SOLD AT ₹ 15,220.00

SKU # 1000084639

ABB XT2 W FP 3p EF Tmax Drawout Conversion Kit 1SDA068200R1

ABB XT2 W FP 3p EF Tmax Drawout Conversion Kit 1SDA068200R1

Visit the ABB Store

₹ 15,220.00

Quantity



Pack Qty : 1

Delivery Availability

Offers and Coupons

Coupon Image

Register to use Coupon Code C50 and get ₹50/- off on a purchase of ₹1000/- & above

PAN INDIA DELIVERY

100% Genuine Products

100% Secured Payments

Product Description

The withdrawable version must be composed as follows
Fixed circuit-breaker
Conversion Kit from fixed into moving part of withdrawable
Fixed part of withdrawable
Front for lever operating mechanism or rotary handle or motor operator
Sliding contacts blocks if the circuit-breaker is automatic or fitted with electrical accessories (only for T7)
For T5 630 -circuit-breaker and switch-disconnector in Plug-in and withdrawable version In max = 570 A

Product Specification

Brand	ABB
Product Type	Drawout Conversion Kit
Product Code	1SDA068200R1
Type	XT2 W FP 3p EF
Technical
Configuration Type	Loose or configurable
Number of Poles	3
Product Main Type	Accessories for Tmax XT
Rated Frequency (f)	50 / 60 Hz
Rated Impulse Withstand Voltage (U_imp)	8 kV
Rated Insulation Voltage (U_i)	1000 V
Rated Operational Voltage	690 V AC 500 V DC
Rated Uninterrupted Current (I_u)	160 A
Standards	IEC 60947
Sub-Type	XT2
Suitable For	XT2
Suitable For Product Class	SACE Tmax XT
Terminal Connection Type	Withdrawable Circuit-Breakers Front Extended
Version	W
Description	FIXED PART WITHDRAWABLE FOR C.BREAKER TMAX THREE-POLE WITH EXTENDED FRONT TERMINALS XT2
Dimensions
Product Net Width	175 mm
Product Net Height	225 mm
Product Net Depth / Length	195 mm
Product Net Weight	1.37 kg
Warranty	As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x B x H
Unit of Measurement
Weight	kg
Generic Type	Drawout Kit
Manufacturer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444
Packer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444
Country of Origin	India
