SKU # 1000130968
Cooler Master Bronze V2 MWE 550 Power Supply HDB Fan MPE-5501-ACABW-BIN
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
DC-to-DC + LLC Circuit Design
-
High Temperature Resistance
-
Peak Power Tolerance
-
80 PLUS Bronze 230V EU Certified
-
Durable, Reliable, and Safe
-
Power Up
-
80 Plus Bronze Certified
-
It's impoIt's important to understand what efficiency is and what the ratings actually mean
-
The efficiency rating indicates how much power is retained and/or lost when transferring it from the wall to your components
-
It does not indicate the overall quality of the PSU
-
A PSU doesn't need an 80 PLUS Gold rating to be safe and reliable
-
And a PSU with an 80 PLUS Gold rating isn't necessarily either of those things
-
The MWE Bronze V2 guarantees a typical efficiency of 85% while being both safe and reliable
-
120mm HDB Fan
-
The constant struggle between cooling and noise is as old as the consumer PC industry itself
-
Keeping your components cool without having to hear about it while you work is still one of the greatest challenges for all fan based cooling technologies
-
The MWE Bronze's solution to this problem is a thermally sensitive 120mm HDB fan
-
It spins based on the system's temperature, constantly adjusting to keep your PSU running smoothly and safely with the minimum amount of noise required
-
Single +Single +12V Rail
-
Getting power from the wall to the PSU and then to your components is a tricky situation
-
The power comes in one voltage level, but your components need a different one
-
That power has to first be transferred to/through a converter in order to make it safe for your parts to use without overloading
-
The lines/rails used to initially move power from the wall to the converter need to be reliable and consistent to ensure your system's overall performance
-
That's why the MWE Bronze only uses one +12V rail for this process
-
This way all the components in your system are constantly fed the same power from the same source in order to guarantee consistency between all connections
-
DC-TO-DC Circuit Design
-
Power comes in multiple voltage levels
-
The wall delivers power in one voltage level but your components each need a specific voltage to operate properly
-
The process of converting raw power from the wall to the multiple voltage levels your components need requires special components to complete this process quickly, efficiently, and safely
-
The MWE Bronze's DC-to-DC + LLC technology was painstakingly crafted to accomplish this goal The Dual Forward circuit layout has been designed to convert 12V power to 3V and 5V levels with minimal ripple noise, 80 PLUS Bronze efficiency, and reduced risk to your connected components
-
Flat Black Cables
-
For many PC BFoFor many PC For many PC Builders with aesthetics in cabling can be one of the most troublesome parts of assembling a PC
-
Cables can be confusing, too short or too long, and they
-
almost never look good
-
The MWE Bronze V2 uses flat and flexible black cables to help deal with these problems cabling
Product Specification
| Brand | Cooler Master |
| Product Type | Power Supply |
| Product Model | MPE-5501-ACABW-BIN |
| Series | MWE Bronze Series |
| ATX Version | ATX 12V V2.52 |
| PFC | Active PFC |
| Input Voltage | 200-240Vac |
| Input Current | 10-5A |
| Input Frequency | 50-60Hz |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Fan Speed | 1500 RPM |
| Noise Level @ 20% | 13.8 dBA |
| Noise Level @ 50% | 18.4 dBA |
| Noise Level @ 100% | 31.2 dBA |
| Efficiency | 88% Typically |
| 80 PLUS Rating | 80 PLUS Bronze EU 230V |
| ErP 2014 Lot 3 | Yes |
| Power Good Signal | 100 - 500 ms |
| Hold Up Time | >14ms at 100% Full Load@230Vac |
| MTBF | >100,000 Hours |
| Protections | OVP, OPP, SCP, UVP, OTP |
| Regulatory | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| SATA Connectors | 6 |
| Peripheral 4 Pin Connectors | 3 |
| PCI-e 6+2 Pin Connectors | 2 |
| 80 Plus | Bronze |
| Modular | Non Modular |
| Category | 500 to 750W |
| Dimensions (L x W x H) | 140 x 150 x 86 mm |
| Warranty | As Per Manufacturer Terms and Condition |
Other Details
| Dimension (CM) - L x B x H | 14 x 15 x 86 |
| Unit Of Measurement | 1 Piece |
| Weight | 5 kg |
| Generic Type | SMPS |
| Manufacturer Details | Cooler Master Technology Inc. 8F., No. 788-1, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan (R.O.C.) |
| Packer Details | Cooler Master Technology Inc. 8F., No. 788-1, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan (R.O.C.) |
| Importer Details | Cooler Master Technology Inc. Shree Ganesh Bhuvan, Shop No 29, Second Floor, 349/363 Lamington Road, Opp Lamington Road Police Station, Mumbai |
| Country Of Origin | China |
