SKU # 1000127696
TSC TE Series 4 Inch Thermal Transfer Desktop Printer TTP 247
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
These enhanced TTP desktop printers feature the same features as their preceding models, plus brand-new state-of-the-art electronics, packing even more performance into an entry-level platform
-
Key Features
-
Up to 177.8 mm (7”) per sec. print speed
-
4 MB Flash memory and 8 MB SDRAM memory
-
SD Flash memory expansion up to 4 GB
-
User-friendly clamshell design
-
Label gap sensor & full-range adjustable black mark sensor
-
Parallel, serial & USB 2.0 interfaces standard
-
Main board integrated with internal Ethernet (factory option)
-
Label capacity up to 214 mm (8.4”) OD
-
Ribbon capacity up to 300 m (984’)
-
TSPL-EZ firmware for plug-n-play ease
-
Optional peel-off module, cutter module,Bluetooth module, stand-alone keyboard
and scanner
-
Applications
-
Business/Office
-
Product Marking
-
Compliance Labeling
-
Asset Tracking
-
Document Management
-
Shelf-Labeling
-
Shipping/Receiving
-
Specimen Labeling
-
Inventory Control
-
Patient Tracking
Product Specification
|
Brand |
TSC |
|
Product Type |
Desktop Printer |
|
Product Model |
TTP 247 |
|
Resolution |
8 dots/mm (203 DPI) |
|
Printing Method |
Thermal Transfer & Direct Thermal |
|
Maximum Print Speed |
178 mm (7”)/second |
|
Maximum Print Width |
108 mm (4.25“) |
|
Maximum Print Length |
2,286 mm (90“) |
|
Label Roll Capacity |
127 mm (5“) OD |
|
Ribbon |
300 m long, max. OD 67 mm, 1” core (ink coated outside) |
|
Ribbon Width |
40 mm ~ 110 mm (1.6” ~ 4.3”) |
|
Processor |
32-bit RISC CPU |
|
Memory |
4
MB Flash memory SD card reader for Flash memory expansion, up to 4 GB |
|
Interface |
USB 2.0 RS-232 Centronics Internal Ethernet, 10/100 Mbps (factory option) Bluethooth (user option) |
|
Power |
External universal switching power supply Input:
AC 100-240V, 2.5A, 50-60Hz |
|
Operation Switch,Button LED |
1 power switch, 1 feed button & 1 LED (3 colors: green, amber & red) |
|
Sensors |
Transmissive
gap sensor |
|
Internal Fonts |
8
alpha-numeric bitmap fonts |
|
Bar Code |
1D Bar Code Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11 2D Bar Code PDF-417, Maxicode, DataMatrix, QR Code, Aztec |
|
Font And Barcode Rotation |
0, 90, 180, 270 degree |
|
Printer Language |
TSPL-EZ |
|
Media Type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
|
Media Width |
20 ~ 112 mm (0.78“ ~ 4.4“) |
|
Media Thickness |
0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) |
|
Media Core Diameter |
25.4 ~ 76.2 mm (1” ~ 3”) |
|
Label Length |
10 ~ 2,286 mm (0.39“ ~ 90“) |
|
Environment Condition |
Operation:
5 ~ 40°C, 25 ~ 85% non-condensing |
|
Safety Regulation |
FCC Class B, CE Class B, C-Tick Class B, UL, CUL, TÜV/Safety, CCC |
|
Environmental Concern |
Comply with RoHS, WEEE |
|
Factory Options |
Internal
Ethernet interface (10/100 Mbps) |
|
Enclosure |
Double-Walled Plastic |
|
Accessories |
Windows
labeling software CD disk Power
cord |
|
Physical Dimension(W x H x D) |
213
x 188 x 314 mm |
|
Weight |
2.5 kg (5.51 lbs) |
|
Warranty |
Limited Warranty Printer: 2 years Print head: 25 km (1 million inches) or 12 months which comes first Platen: 50 km (2 million inches) or 12 months which comes first |
Other Details
|
Dimension (MM) - L x B x H |
213 x 188 x 314 |
|
Unit of Measurement |
1 Piece |
|
Weight |
2.5 kg |
|
Generic Type |
Thermal Printer |
|
Manufacturer Details |
TSC
India Representative Office India |
|
Packer Details |
TSC
India Representative Office India |
|
Country of Origin |
India |
