SKU # 1000138980
V-Guard Classio Plus Triple Layer PVC Insulated Wiring Cable 90 Mtrs 1.5 Sq.mm
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Salient Features
Triple Layer Insulation for better safety
Moisture guard resists moisture, ensuring long-lasting safety & protection
High ageing property of PVC insulation
High conductivity of copper (102% IACS) & low conductor resistance
99.97% pure copper
Pulling easiness prevents friction inside conduit and offers easiness in installation
Anti-termite insulation to resist the termite attack on PVC insulation
Extra flexible for easy wiring
Superior insulation resistance helps reduce leakage, leading to lesser chances of failure during extended use
“90 m ASSURED” seal on cable
100% bunching
Voltage grade: up to and including 1100 V
Application
House wiring cables for indoor electrification and power supply to all electrically operated equipment (Eg: Fans, Lights, Home Appliances, etc.)
Features
Anti Termite
Anti Aging
Moisture Guard
High Flame Retardancy
Xtra Flex
3 Layer Insulation
-
99.97% Pure Copper
Product Specification
| Brand | V-Guard |
| Product Type | Wires |
| Product Model | Classio Plus |
| Colours | Red Yellow Blue Black Green Grey White |
| Cable Length | 90 Mtrs |
| Conductor Nominal Area | 1.5 Sq.mm |
| Number & Nominal Diameter Of Wire | 30/.25 No./mm |
| Resistance (Maximum) per km. @ 20°C | 13.3 Ohm |
| Approximate Over All Diameter | 2.8 mm |
| Nominal Thickness Of Insulation | 0.6 mm |
| Current Carrying Capacity Two Cables, Single Phase In Conduit/Trunking | 13 Amp |
| Current Carrying Capacity Two Cables, Single Phase Unenclosed-Clipped Directly To A Surface Or On Cable Tray | 16 Amp |
| Warranty | As Per Manufacturer Terms and Condition |
Other Details
| Dimension (CM) - L x B x H | 23.6 x 23.3 x 6 |
| Unit of Measurement | 1 Roll |
| Weight | 1 kg |
| Generic Type | Wires |
| Manufacturer Details | V-GUARD INDUSTRIES LTD. Regd. Office: 42/962, Vennala High School Road, Vennala, Kochi - 682028 Phone : +91 484 433 5000 Email: mail@vguard.in |
| Packer Details | V-GUARD INDUSTRIES LTD. Regd. Office: 42/962, Vennala High School Road, Vennala, Kochi - 682028 Phone : +91 484 433 5000 Email: mail@vguard.in |
| Country of Origin | India |
