SKU # 1000071608
Fluke Infrared Thermometer 566
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Two-in-one IR and contact thermometer with a 30:1 distance-to-spot ratio
-
Measures temperatures from -40°C to 650°C (40°F to 1202°F)
-
Makes it easy to access advanced features with the soft-key buttons and graphical display
-
Features rugged, ergonomic design that stands up to tough industrial, electrical, and mechanical environments
-
Works with most K-type thermocouples
-
Adjustable emissivity that allows you to confidently measure a wide variety of surfaces
-
Up to 20 points of data for downloading and recalling later
-
Two levels of backlight on the display
-
Features audible and visual alarms to instantly alert you to measurements outside of your set limits
-
Provides MAX, MIN, DIF and AVG functions to quickly identify problems
Product Specification
|
Brand |
Fluke |
|
|
Product Type |
Infrared Thermometer |
|
|
Product Model |
566 |
|
|
Infrared Temperature Range |
-40 °C to 650 °C (-40 °F to 1202 °F) |
|
|
Infrared Accuracy |
< 0 °C (32 °F): ± (1.0 °C (± 2.0 °F) + 0.1°/1 °C or °F); > 0 °C (32 °F): ± 1 % or ± 1.0 °C (± 2.0 °F), Whichever Is Greater |
|
|
Display Resolution |
0.1 °C / 0.1 °F |
|
|
Infrared Spectral Response |
8 μm to 14 μm |
|
|
Infrared Response Time |
< 500 msec |
|
|
Thermocouple Type-K Input Temperature Range |
-270 °C to 1372 °C (-454 °F to 2501 °F) |
|
|
Thermocouple Type-K Input Accuracy |
-270°C to -40°C |
±(1°C + 0.2°/1°C) (-454°F to -40°F: ±(2°F + 0.2°/1°F)) |
|
-40°C to 1372°C |
±1% or 1°C (-40°F to 2501°F: ±1% or 2°F), whichever is greater |
|
|
D:S (Distance To Measurement Spot Size) |
30:1 |
|
|
Laser Sighting |
Single-Point Laser < 1 mw Output Class 2 (ii) Operation, 630 Nm To 670 nm |
|
|
Minimum Spot Size |
19 mm (0.75 in) |
|
|
Emissivity Adjustment |
By Built-In Table Of Common Materials Or Digitally Adjustable From 0.10 To 1.00 By 0.01 |
|
|
Data Storage With Date/Time Stamp |
20 points |
|
|
PC Interface and Cable |
None |
|
|
Hi/Low Alarms |
Audible and two-color visual |
|
|
Min/Max/Avg/Dif |
Yes |
|
|
Display |
Dot Matrix 98 X 96 Pixels With Function Menus |
|
|
Backlight |
Two Levels, Normal And Extra Bright For Darker Environments |
|
|
Trigger Lock |
Yes |
|
|
Switchable Celsius and Fahrenheit |
Yes |
|
|
Power |
2 AA/LR6 Batteries |
|
|
Battery life |
If Used Continuously |
Laser and Backlight On, 12 Hours Laser and Backlight Off, 100 Hours |
|
Operating Temperature |
0 °C to 50 °C (32 °F to 122 °F) |
|
|
Storage Temperature |
-20 °C to 60 °C (-40 °F to 140 °F) |
|
|
Bead Thermocouple Type-K Range |
-40 °C to 260 °C (-40 °F to 500 °F) |
|
|
Bead Thermocouple Type-K Accuracy |
± 1.1 °C (2.0 °F) from 0 °C to 260 °C (32 °F to 500 °F), Typically Within 1.1 °C (2.0 °F) from -40 °C to 0 °C (-40 °F to 32 °F) |
|
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Infrared Thermometers |
Manufacturer Details |
Fluke, Fluke Technologies Pvt Ltd, Art Guild House, Kurla West Mumbai-400070 |
Packer Details |
Fluke, Fluke Technologies Pvt Ltd, Art Guild House, Kurla West Mumbai-400070 |
Country of Origin |
India |
