SKU # 1000139342
CP Plus 16 Channel Network Video Recorder Without HDD CP-UNR-4K2161-V4
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Key Features
Up to 16 channel IP camera input
Instastream, H.265, H.264 , H.264, MJPEG Decoding
Max. decoding capability: 6 × 1080p@30 fps
Max. 144/144/72 Mbps incoming/recording/outgoing bandwidth
Support 1 SATA HDDs up to 20TB Each, 2 USB Ports, 1 HDMI, 1 VGA
AI by Camera: Perimeter protection, SMD
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro Lite
Functions
Instastream
This camera has been designed with the latest and most efficient innovation among the standard video compression designs
Smart encoding algorithms developed by CP Plus help in saving up to 70% more bandwidth than H.265 along with making it more beneficial for minimizing bandwidth and storage costs
It enhances video coding efficiency while providing high resolution and the rate of frame in the video using Intelligent Region Perception to detect motion in each
gCMOB/ iCMOB
Designed to allow users to access and control live streaming from CP Plus IP Cameras, DVRs/ NVRs and Video Door Phones, the CP Plus gCMOB/ iCMOB application offers a host of features such as Easy GUI, up to 16 live viewing split-ups; InstaOn cloud support; Playback; digital zoom ins; two-way talk, and more
KVMS Pro Lite
The KVMS Pro Lite is a hybrid security management software that allows the management of various surveillance devices such as cameras, DVRs/ NVRs, encoders/ decoders, etc
It is released with the surveillance hardware and exclusively supports CP Plus devices
Smart Motion Detection (SMD)
CP Plus has introduced Smart Motion Detection, AI-based SMD, which use an advanced algorithm to differentiate human and vehicular shapes within a scene and send alarms only when a person or vehicle is detected
-
Note:*Actual product image may vary from that shown on the picture
Product Specification
|
Brand |
CP Plus |
|
Product Type |
NVR |
|
Product Model |
CP-UNR-4K2161-V4 |
|
Processor |
Industrial-grade processor |
|
Operating System |
Embedded Linux |
|
IP Camera Input |
16 channel |
|
User Interface |
Web, Local GUI |
|
AI By Camera |
Perimeter protection, SMD |
|
AI By NVR |
SMD |
|
Perimeter Performance Of AI By Camera |
All channels (4 targets/s) |
|
Video Output |
1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
|
Resolution |
12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, 960p, D1, CIF, QCIF |
|
Network Bandwidth |
AI disabled: 144 Mbps incoming, 144 Mbps recording and 72 Mbps outgoing AI enabled: 72 Mbps incoming, 72 Mbps recording and 36 Mbps outgoing |
|
Decoding Capability |
AI Disabled: 1 channel 12 MP@30 fps, 1 channel 8 MP@30 fps, 2 channel 6 MP@30 fps, 2 channel 5 MP@30 fps, 3 channel 4 MP@30 fps, 6 channel 1080p@30 fps AI Enabled: 1 channel 8 MP@30 fps, 1 channel 6 MP@30 fps, 1 channel 5 MP@30 fps, 2 channel 4 MP@30 fps, 4 channel 1080p@30 fps |
|
Video Display Split |
1/4/8/9/16 |
|
Video Compression |
Instastream, H.265, H.264+, H.264, MJPEG |
|
Hard Disk |
1 SATA port, Each disk can contain up to 20 TB. This limit varies depending on the environment temperature |
|
General Alarm |
Motion detection, Camera external alarm, PIR alarm |
|
Intelligent Alarm |
Perimeter protection, SMD Plus |
|
Alarm Linkage |
Recording, Snapshot, Buzzer, Log, Preset, Email, Tour |
|
Playback |
Instant playback, General playback, Event playback, Tag playback, Smart playback |
|
Multi-Channel Playback |
Up to 16 channels |
|
SMD Plus By Camera |
All channels (8 targets/s) |
|
SMD Plus By NVR |
4 channels: Secondary filtering for human and motor vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change |
|
Abnormality Alarm |
Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline |
|
Protocols |
HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, IP Search (Supports IP camera, DVR, NVS, etc.), InstaOn, Auto Registration, ONVIF (Profile T, Profile S, Profile G), CGI, SDK |
|
Audio Input |
1 channel RCA |
|
Audio Output |
1 channel RCA |
|
Audio Compression |
G.711a, G.711u, PCM, G726, AAC |
|
Recording Mode |
General, Motion detection, Intelligent, Alarm |
|
Interface Ports |
2 (1 front USB 2.0 port, 1 rear USB 2.0 port), 1 HDMI, 1 VGA |
|
Ethernet |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
|
Backup Mode |
USB device and network |
|
Smart Phone |
iOS, Android |
|
Browser |
Chrome, IE, Safari, Edge, Firefox |
|
Power Supply |
12 VDC, 1.5 A |
|
Power Consumption |
<10 W (without HDD) |
|
Operating Temperature |
–10°C to +55°C (14°F to +131°F) |
|
Operating Humidity |
10%–93% (RH), non-condensing |
|
Storage Temperature |
–20°C to +60°C (–4°F to +140°F) |
|
Dimension |
260 × 232.5 × 47.6 mm |
|
Weight |
0.85 kg |
|
Warranty |
As Per Manufacturer Terms And Conditions |
Other Details
|
Dimension (CM) L x B x H |
26 x 23.2 x 4.7 |
|
Unit Of Measurement |
1 Piece |
|
Weight |
1 kg |
|
Generic Name |
16 Channel NVR |
|
Manufacturer Details |
Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526 |
|
Packer Details |
Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526 |
|
Country Of Origin |
India |
