48 hours

SKU # 1000131763


Selec Din Rail Mount Power Supply 60 W RPS60-48-CU

Selec Din Rail Mount Power Supply 60 W RPS60-48-CU


₹ 1,870.00

Quantity

Pack Qty : 1



Delivery Availability

 Estimated Dispatch Within 2 Days

EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • Supports 90 - 264 VAC / 127 - 370 VDC

  • Efficiencies up to 87 %

  • Protection against short circuit, overload, overvoltage & over temperature

  • Cooling by free air convection

  • UL 508 approved (E522848)

Product Specification

Brand

Selec

Product Type

Power Supply

Product Model

RPS60-48-CU

Description

60W, 48V/1.25A DIN rail mounted Power Supply in Plastic Housing

Input Voltage

90 - 264 VAC (127 - 370 VDC)

Input Frequency

50/60 Hz

Inrush Current

< 48 Amps; Measured at 264 VAC, 25°C Ambient, Cold start

Output Voltage

5V to 48V

Output Power

60 W

Voltage Tolerance

± 1 %

Line Regulation

< 1% of Vout

Load Regulation

± 1 %

Turn On Time

< 1 sec @ 230 VAC & < 3 sec @ 115 VAC, Full load

Hold Up Time

60ms at 230V AC & ≥15ms at 115V AC, Full load

Rise Time

< 100 ms

Overload Protection

> 110% of rated output current; Hiccup type; Autorecovery

Overvoltage Protection

Latched type; Input AC power to be recycled to recover the power supply

Output Short Circuit Protection

Hiccup mode when output is shorted; Autorecovery type

Operating Temperature

- 25°C to + 70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C,- 25°C to 0°C start-up is guaranteed with specification deviation

Storage Temperature

- 40°C to + 85°C

Cooling

Natural convection cooled

Humidity

5 to 95 % RH, Non condensing

Altitude

2000 m

Mounting

35 mm Din rail

Dimension (W x H x D)

43 x 109.8 x 102.7 mm

Weight

285 g

Warranty

As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x B x H

9.6 x 9.6 x 6.2

Unit Of Measurement

1 Piece

Weight

0.5 kg

Generic Type

Power Supplies

Manufacturer Details

Selec Controls Pvt. Ltd. EL-27/1, Electronic Zone, TTC Industrial Area, MIDC, Mahape Navi Mumbai - 400 710, Maharashtra. Phone : 91-22-41418468 Email: enquiry@selec.com

Packer Details

Selec Controls Pvt. Ltd. EL-27/1, Electronic Zone, TTC Industrial Area, MIDC, Mahape Navi Mumbai - 400 710, Maharashtra. Phone : 91-22-41418468 Email: enquiry@selec.com

Country Of Origin

India
