ABB XTMax MCCB 1.6-160A 50KA 415V Ac Four-Pole - XT2S 160 4p

ABB XTMax MCCB 1.6-160A 50KA 415V Ac Four-Pole - XT2S 160 4p

₹ 14,940.00

Quantity

Pack Qty : 1



Delivery Availability
Offers and Coupons
Coupon Image

Register to use Coupon Code C50 and get Rs. 50/- off on a purchase of Rs. 1000/- & above

EMI Icon

EMI Available On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • C.Breaker Tmax XT2S 160 Fixed Four-Pole With Front Terminals And Thermomagnetic Release TMD

  • Moulded-case circuit-breakers can be used in low voltage civil and industrial installations with 1 to 3200 A operating current.

  • The ultimate short-circuit breaking capacity (Icu) at 415V ranges from 18kA to 200kA, or up to 100kA for 690V.

  • Product Name : Moulded Case Circuit Breaker

  • Product Main Type : SACE Tmax XT

  • Product Type : CB

  • Number of Poles : 3

  • Product Net Weight : 1.6 kg

  • Product Net Width : 120 mm

  • Product Net Height : 130 mm

  • Product Net Depth / Length : 82.5 mm

  • Rated Operational Voltage:690 V AC , 500 V DC

  • Electrical Durability : 120 cycles per hour , 8000 cycle

  • Mechanical Durability : Nr. Operations 240 cycles per hour, Nr. Operations 25000 cycle

  • Terminal Connection Type : Fixed Circuit-Breakers Front

  • Standards:IEC

  • Version : F

Product Specification

Rated current

Type

Product id

1.6 A

1SDA067561R1

XT2S 160 TMD 1,6-16 4p F F

2 A

1SDA067562R1

XT2S 160 TMD 2-20 4p F F

2.5 A

1SDA067563R1

XT2S 160 TMD 2,5-25 4p F F

3.2 A

1SDA067564R1

XT2S 160 TMD 3,2-32 4p F F

4 A

1SDA067565R1

XT2S 160 TMD 4-40 4p F F

5 A

1SDA067566R1

XT2S 160 TMD 5-50 4p F F

6.3 A

1SDA067567R1

XT2S 160 TMD 6,3-63 4p F F

8 A

1SDA067568R1

XT2S 160 TMD 8-80 4p F F

10 A

1SDA067569R1

XT2S 160 TMD 10-100 4p F F

12.5 A

1SDA067570R1

XT2S 160 TMD 12,5-125 4p F F

16 A

1SDA067571R1

XT2S 160 TMD 16-300 4p F F

20 A

1SDA067572R1

XT2S 160 TMD 20-300 4p F F

25 A

1SDA067573R1

XT2S 160 TMD 25-300 4p F F

32 A

1SDA067574R1

XT2S 160 TMD 32-320 4p F F

40 A

1SDA067575R1

XT2S 160 TMA 40-400 4p F F

50 A

1SDA067576R1

XT2S 160 TMA 50-500 4p F F

63 A

1SDA067577R1

XT2S 160 TMA 63-630 4p F F

80 A

1SDA067578R1

XT2S 160 TMA 80-800 4p F F

100 A

1SDA067579R1

XT2S 160 TMA 100-1000 4p F F

125 A

1SDA067582R1

XT2S 160 TMA 125-1250 4p F F InN=100%

160 A

1SDA067583R1

XT2S 160 TMA 160-1600 4p F F InN=100%

Other Details

Dimension (CM) - L x B x H

Unit of Measurement

Weight

kg

Generic Type

4 Pole MCCB

Manufacturer Details

ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444

Packer Details

ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444

Country of Origin

India
