Out of Stock!
SKU # 1000076165
Dahua Entry IR Network Camera 4MP DH-IPC-K42P
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
4MP, 1/3” CMOS image sensor, low illuminance, high image definition
-
Outputs max. 4MP (2560 × 1440) 25/30 fps
-
H.265 codec, high compression rate, ultra-low bit rate
-
Max. IR distance: 10 m
-
Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
-
H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
-
Alarm: 1 in, 1 out; 256 G SD card, built-in Mic and speaker
-
Supports 256 G Micro SD card
-
12V DC power supply, easy for installation
-
Supports PIR
-
Supports Wi-Fi
-
Features
-
Smart H.265+ & Smart H.264+
-
Smart Illumination
-
Wide Dynamic Range (WDR)
-
Motion Detection
-
Day/Night
-
Voice Call
Product Specification
Brand |
Dahua |
||
Product Type |
Network Camera |
||
Series |
Entry |
||
Product Code |
DH-IPC-K42P |
||
Camera | |||
Image Sensor |
1/3”4Megapixel progressive CMOS |
||
Max. Resolution |
2560 (H) × 1440 (V) |
||
Rom |
128 MB |
||
Ram |
128 MB |
||
Scanning System |
Progressive |
||
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
||
Min. Illumination |
Manual 1/30 s 0. 170 Lux F2.0 (Color, 80 IRE); 0.165 Lux F2.0 (W/B, 80 IRE); 0 Lux (IR on) Manual 1/3 s 0.0141 Lux F2.0 (Color, 80 IRE); 0.0116 Lux F2.0 (W/B, 80 IRE); 0 Lux (IR on) |
||
S/N Ratio |
>46.6 dB |
||
Illumination Distance |
10 m (32.8 ft) (IR LED) |
||
Illuminator On/Off Control |
Auto |
||
Illuminator Number |
1 (IR LED) |
||
Pan/Tilt/Rotation Range |
Pan: 0°–360° Tilt: 0°–90° |
||
Lens | |||
Lens Type |
Fixed-focal |
||
Mount Type |
M12 |
||
Focal Length |
2.8 mm |
||
Max. Aperture |
F2.0 |
||
Field Of View |
Horizontal: 97° Vertical: 52° Diagonal: 116° |
||
IRIS Type |
Fixed |
||
Close Focus Distance |
0.8 m (2.6 ft) |
||
Dori Distance | |||
Detect |
Observe |
Recognize |
Identify |
56.0 M (183.7ft) |
22.4 M (73.5 Ft) |
11.2 m (36.7 ft) |
5.6 m (18.4 ft) |
Video | |||
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
||
Smart Codec |
H.264: Yes H.265: Yes |
||
Video Frame Rate |
50 Hz Main stream (2560 × 1440 25 fps), sub stream (640 × 480 25 fps) Main stream (2304 × 1296 25 fps), sub stream (640 × 360 25 fps) Main stream (1920 × 1080 25 fps), sub stream (320 × 240 25 fps) 60 Hz Main stream (2560 × 1440 30 fps), sub stream (640 × 480 30 fps) Main stream (2304 × 1296 30 fps), sub stream (640 × 360 30 fps) Main stream (1920 × 1080 30 fps), sub stream (320 × 240 30 fps) |
||
Stream Capability |
2 streams |
||
Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); VGA (640 × 480); 640 × 360; QVGA (320 × 240) |
||
Bit Rate Control |
CBR/VBR |
||
Video Bit Rate |
"H.264: 184 kbps–6144 kbps H.265: 73 kbps–6144 kbps" |
||
Day/Night |
Auto (ICR)/Color/B/W |
||
BLC |
Yes |
||
Hlc |
Yes |
||
WDR |
DWDR |
||
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
||
Gain Control |
Auto/Manual |
||
Noise Reduction |
3D DNR |
||
Motion Detection |
OFF/ON (4 areas, rectangular) |
||
Region Of Interest (roi) |
Yes (4 areas) |
||
Smart Illumination |
Yes |
||
Image Rotation |
0°/90°/180°/270° |
||
Mirror |
Yes |
||
Privacy Masking |
4 areas |
||
Audio | |||
Built-In Mic |
Yes |
||
Audio Compression |
AAC; G.711a; G.711Mu |
||
Alarm | |||
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering |
||
Network | |||
Network |
RJ-45 (10/100 Base-T) |
||
Wi-Fi |
Yes |
||
Sdk And Api |
Yes |
||
Protocol |
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; QoS; NTP |
||
Interoperability |
ONVIF (Profile T/Profile S/Profile G); CGI; DMSS |
||
User/Host |
20 (Total bandwidth: 100 M) |
||
Storage |
NAS; FTP; SFTP; Micro SD card (256 G) |
||
Browser |
IE: IE7 and later Chrome: Chrome 45 and later Firefox: FireFox 46 and later Safari: Mac os Safari12 |
||
Management Software |
DMSS |
||
Mobile Phone |
IOS; Android |
||
Certification |
CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU CE-RED: Radio Equipment Directive 2014/53/EU FCC: 47 CFR FCC Part 15, Subpart B FCC ID: FCC PART 15C |
||
Port | |||
Alarm Input |
1 channel in: 5mA 3V–5V DC |
||
Alarm Output |
1 channel out: 300mA 12V DC |
||
Power | |||
Power Supply |
12V DC |
||
Power Consumption |
Max 3.3W (12V DC) |
||
Environment | |||
Operating Conditions |
–10°C to +45°C (14°F to +113°F)/Less than 95%RH |
||
Storage Conditions |
–40°C to +60°C (–40°F to +140°F) |
||
Structure | |||
Casing |
Plastic |
||
Dimensions |
Φ78.5 mm × 90.5 mm × 127.8 mm (3.1" × 3.6" × 5.0") (L × W × H) |
||
Net Weight |
160 g (0.4 lb) |
||
Gross Weight |
360 g (0.8 lb) |
||
Warranty |
As Per Manufacturer Terms and Condition |
||
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Network Camera |
Manufacturer Details |
Dahua Technology Co., Ltd. No.1199, Bin'an Road, Binjiang District, Hangzhou, China. |
Packer Details |
Dahua Technology Co., Ltd. No.1199, Bin'an Road, Binjiang District, Hangzhou, China. |
Importer Details |
Dahua Technology India Pvt.Ltd. 122, Bhagwan Mahaveer Marg, Sector 44, Gurugram, Haryana 122003 Phone: 0124 456 9100 |
Country of Origin |
China |
