Out of Stock!

SKU # 1000122409

CP Plus 2.4MP IR Vandal Dome Camera 30Mtr CP-USC-VA24ZR3

CP Plus 2.4MP IR Vandal Dome Camera 30Mtr CP-USC-VA24ZR3

₹ 4,320.00

Quantity

Pack Qty : 1



Delivery Availability
Offers and Coupons
Coupon Image

Register to use Coupon Code C50 and get Rs. 50/- off on a purchase of Rs. 1000/- & above

EMI Icon

EMI Available On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • 1/2.7" 2.4MP PS CMOS Image Sensor (0.9407 centimeters)

  • Max 25/30fps@2.4MP

  • DWDR, Day/Night (ICR), 2D-DNR, AWB, AGC, BLC, HLC

  • 2.7mm~12mm Motorized Lens

  • IR Range of 30Mtrs., Smart IR, IP67, IK10

  • OSD Menu,control over coaxial cable, 2D-DNR

  • CVI/CVBS/AHD/TVI switchable

  • Functions

  • OSD Menu Support

  • CP PLUS HD analog cameras come with their own menu using which the camera settings can be managed,for instance,the signal type can be changed and other sensor level adjustments be made

  • IR LED

  • Numerous IR LEDs provide detailed images even in very low light conditions

  • These LEDs adjust the infrared intensity for distinct images in dark environments for up to 30mtrs

  • UNI+ Technology

  • CP PLUS Analog HD cameras offer compatibility across all the available technologies - CVBS, TVI, HDCVI, AHD and Hdx, making upgrading simple and hassle-free

  • Power Protection

  • With a voltage tolerance range of ±30, these cameras are suitable even in fluctuating power conditions

  • Plug & Play

  • CP PLUS Analog HD cameras are simple to configure and in-stall

Product Specification

Brand

CP Plus

Product Type

Dome Camera

Product Model

CP-USC-VA24ZR3

Image Sensor

1/2.7" 2.4MP PS CMOS (0.9407 centimeters)

Minimum Illumination

0.02Lux/F1.7, 30IRE, 0Lux IR on

Effective Pixels

2.4MP

Shutter Speed

PAL: 1/25~1/100000s NTSC: 1/30~1/100000s

White Balance

Auto / Manual

Gain Control (AGC)

Auto

Lens

2.7~12mm

Lens Type

Motorized

Iris Type

Fixed-Iris

Mount Type

φ14

Maximum Aperture

F1.7

Day/Night

Auto switch by ICR

S/N Ratio

>65dB

Noise Reduction

2D-DNR

Angle Of View

Diagonal: 38°– 125° Horizontal: 33°–102° Vertical: 19°– 53°

Close Focus Distance

1.2m

DORI Distance

2.7mm: 49.7m(Detect); 19.9m(Observe); 9.9m(Recognize); 5m (Identify)
12mm: 82.8m(Detect); 33.1m(Observe); 16.6m(Recognize); 8.3m (Identify)

Back Light Compensation

BLC/HLC/DWDR

Video Streaming

CVI: 2.4MP@25/30fps; 720P@25/30fps; 720P@50/60fps; AHD: 2.4MP@25/30fps;
720P@25/30fps; TVI: 2.4MP@25/30fps; 720P@25/30fps; 720P@50/60fps;
CVBS: 960H

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

IR LED Number

2

IR

IR Range of 30 Mtr

Smart IR

Yes

Mirror

Off/On

Electronic Defog

Yes

Privacy Masking

Off/On (8 area, rectangle)

Weatherproof Standard

IP67 & IK10

Casing

Plastic dome cover + metal upper casing + metal pedesta

Operating Temperature

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% (non-condensation)

Power Source

12V DC ±30%

Power Consumption

Maximum 6.3W (12V DC, IR on)

Colour

White

Warranty

As Per Manufacturer Terms And Conditions

Other Details

Dimension (MM) ΦxH

122 x 88.9

Unit Of Measurement

1 Piece

Weight

0.440 kg

Generic Name

Dome Camera

Manufacturer Details

Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526

Packer Details

Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526

Country Of Origin

India
