SKU # 1000074600
Dahua Lite Series HDCVI IR Eyeball Camera 2MP DH-HAC-HFW1220RP-Z-IRE6
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Max 30fps@1080P
-
HD and SD output switchable
-
2.7-12mm Motorized lens
-
Max. IR length 60m, Smart IR
-
IP67, DC12V
-
Functions
-
4 Signals over 1 Coaxial Cable
-
Long Distance Transmission
-
Simplicity
-
Smart IR
-
Multi-formats
-
Multi-language OSD
-
Protection
Product Specification
Brand |
Dahua |
|||
Product Type |
Bullet Camera |
|||
Series |
Lite Series |
|||
Product Model |
DH-HAC-HFW1220RP-Z-IRE6 |
|||
Camera | ||||
Image Sensor |
1/2.7" CMOS |
|||
Effective Pixels |
1920(H)×1080(V), 2MP |
|||
Scanning System |
Progressive |
|||
Electronic Shutter Speed |
PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
|||
Minimum Illumination |
0.02Lux/F1.8, 30IRE, 0Lux IR on |
|||
S/N Ratio |
More than 65dB |
|||
Ir Distance |
Up to 60m (197feet) |
|||
Ir On/Off Control |
Auto / Manual |
|||
Ir Leds |
4 |
|||
Lens | ||||
Lens Type |
Motorized lens / Fixed iris |
|||
Mount Type |
Board-in |
|||
Focal Length |
2.7-12mm |
|||
Max Aperture |
F1.8 |
|||
Angle Of View |
H: 105.9°~33.4° |
|||
Focus Control |
Motorized |
|||
Close Focus Distance |
200mm 7.87'' |
|||
Dori Distance | ||||
Dori Definition |
Distance |
|||
Wide |
Tele |
|||
Detect |
25px/m (8px/ft) |
45m(148ft) |
132m(433ft) |
|
Observe |
63px/m (19px/ft) |
18m(59ft) |
53m(173ft) |
|
Recognize |
125px/m (38px/ft) |
9m(30ft) |
26m(87ft) |
|
Identify |
250px/m (76px/ft) |
5m(15ft) |
13m(43ft) |
|
Pan/Tilt/Rotation |
Pan: 0° ~ 360° Tilt: 0° ~ 87° Rotation: 0° ~ 360° |
|||
Video | ||||
Resolution |
1080P (1920×1080) |
|||
Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
|||
Video Output |
1-channel BNC high definition video output / CVBS video output (Can switch) |
|||
Day/Night |
Auto (ICR) / Manual |
|||
Osd Menu |
Multi-language |
|||
Blc Mode |
BLC / HLC / DWDR |
|||
Wdr |
DWDR |
|||
Gain Control |
AGC |
|||
Noise Reduction |
2D |
|||
White Balance |
Auto / Manual |
|||
Smart Ir |
Auto / Manual |
|||
Certifications |
CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|||
Interface | ||||
Audio Interface |
N/A |
|||
Electrical | ||||
Power Supply |
12V DC ±30% |
|||
Power Consumption |
Max 12.1W (12V DC, IR on) |
|||
Environmental | ||||
Operating Conditions |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH * Start up should be done at above -30°C (-22°F) |
|||
Storage Conditions |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH |
|||
Ingress Protection & Vandal Resistance |
IP67 |
|||
Construction | ||||
Casing |
Aluminium |
|||
Dimensions |
213mm×90.4mm×90.4mm (8.39"×3.56"×3.56") |
|||
Net Weight |
0.55kg (1.21lb) |
|||
Gross Weight |
0.70kg (1.54lb) |
|||
Warranty |
As Per Manufacturer Terms and Condition |
|||
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Dome Camera |
Manufacturer Details |
Dahua Technology Co., Ltd. No.1199, Bin'an Road, Binjiang District, Hangzhou, China. |
Packer Details |
Dahua Technology Co., Ltd. No.1199, Bin'an Road, Binjiang District, Hangzhou, China. |
Importer Details |
Dahua Technology India Pvt.Ltd. 122, Bhagwan Mahaveer Marg, Sector 44, Gurugram, Haryana 122003 Phone: 0124 456 9100 |
Country of Origin |
China |
